WLED Addressable Strip Controller
ESP32-WROOM-32E Chipset
2 Channels
I2S PDM Digital Microphone Built in
IR Remote Control (optional)
Input: 5V-24V
MaxLoad: 16 A
16A Relay Switch
Strip types support: WS2812B WS2811 WS2813 WS2815 SK6812 TM1814 APA102 WS2801 LDP8806 GS8208
GPIO:
- Button(GPIO0)
- Relay(GPIO2)
- DATA1(GPIO18)
- DCLK1(PGIO5)
- DATA2(GPIO17)
- DCLK2(PGIO16)
- IR(GPIO25)
- I2S_SDPIN(GPIO32 )
- I2S_WSPIN(GPIO15 )
- I2S_CKPIN(-1)
Note:
Official WLED firmware does't support Sound Effective and Default infrared HEX Codes does not match our Remote control properly, Upgrade Official firmware will lose Sound Effects and IR functions. To build your own firmware please reference source code of our version on Github
https://github.com/athom-tech/Sound-Reactive-WLED
The device firmware uses DATA1 (GPIO18) as the DATA of the WS281X type light strip by default. If you have other types of light strips, please set it on the setting page according to your actual situation
